Flooring/decking wood to wood screw 4,2x40mm

Specifications

Identificaton

Article number

42RI40MX

GTIN

8715274297286

Technical specifications

Collation type

Plastic collated

Wire material

Stainless steel AISI 316 (A4)

Rotations per minute

2300, 2500, 3000, 3300 RPM

Fastener specifications

Application environment

Outdoor

Screw head type

Small with 4 nibs

Screw recess

Torx 20

Screw thread type

2/3 coarse

Screw length

40.0 mm

Screw diameter

4.2 mm

CE Specifications

Characteristic head pull through parameter

16.0 N/mm²

DOP No

42RI40MX

Service class

3

Inner threaded diameter

2.63 mm

Threaded/profiled length

40.0 mm

Characteristic yield moment

2400.0 Nmm

Torsional ratio

≥ 1,5

Characteristic torsional resistance

1.88 Nm

Characteristic torsional strength

3.47 Nm

Characteristic tensile capacity

3200.0 N

Harmonized standard

EN 14592:2008+A1:2012

Characteristic withdrawal parameter

12.0 N/mm²

Non-technical specifications

Package quantity

1000
