N staple AISI304, Sencoted

N staple 50mm AISI304 ETA

tap image to zoom

Description

N staple AISI304, Sencoted

Read more Read less

Applications

Cabinets, Casing, Drawers, Upholstering, Soffits, Underlayment, Lattice, Sheathing

Read more Read less

Norm

Harmonized standard EAD 130019-00-0603 (09-2016)

Request information

Specifications

Identificaton

Article number: N21BGB-ETA
GTIN: 8715274239378

Technical specifications

Collation angle: 0 °
Collation type: Glue collated
Wire material: Stainless steel AISI 304 (A2)
Gauge: 16

Fastener specifications

Coating: Sencoted
Application environment: Outdoor
Point type: Chisel
Pointangle: 70 °
Staple type: Heavy wire staple
Staple thickness: 1.4 mm
Staple wire size: 1.51 mm
Staple crown width: 10.6 mm
Staple inside width: 7.67 mm
Staple serie: N staple
Amount fasteners on strip/coil: 69 - 71
Staple length: 50.0 mm

CE Specifications

Characteristic head pull through parameter: 41.0 N/mm²
CE fastener type: Deformed circular cross-section staple
DOP No: DOP# SSETA-8120
Coating type: Coating type 3
Coating length: 50.0 mm
Characteristic yield moment: 0.71 Nmm
Characteristic tensile strength: 900.0 N/mm²
Harmonized standard: EAD 130019-00-0603 (09-2016)

Non-technical specifications

Package quantity: 10000

Logistical specifications

Net weight: 15.5 kg
